Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tray
Status Obsolete
Core Processor PowerPC e300
Number of Cores/Bus Width 1 Core, 32-Bit
Speed 533MHz
Co-Processors/DSP Security; SEC
RAM Controllers DDR
Graphics Acceleration No
Ethernet 10/100/1000Mbps (2)
USB USB 2.0 + PHY (2)
Voltage - I/O 2.5V, 3.3V
Temperature Range - Operating 0°C ~ 105°C
Security Features Cryptography, Random Number Generator
Manufacturer Package 672-LBGA
Supplier Device Package 672-TBGA (35x35)
Additional Interfaces DUART, I2C, PCI, SPI
Family Part Number MPC8347
Manufacturer Pack Quantity 24
MSL Level 3 (168 Hours)
Win Source Part Number 719569-MPC8347EVVAJF
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MPC8347EVVAJF CAD Model

Description

Product Overview: NXP MPC8347EVVAJF

The NXP MPC8347EVVAJF is a high-performance, power-efficient integrated processor designed to meet the demanding needs of embedded networking and computing applications. This processor is part of the MPC83xx PowerQUICC II Pro family, which is renowned for its exceptional integration, versatility, and system performance. The MPC8347EVVAJF is built on Power Architecture technology, ensuring compatibility with a wide range of software and hardware tools.

Key Features

  • Core: The processor features a PowerPC e300 core with speeds up to 400 MHz, providing a balance of processing power and energy efficiency.
  • Memory Support: It includes DDR and DDR2 SDRAM memory controller options, offering flexibility in memory configurations to match specific application requirements.
  • Integrated Peripherals: The processor comes with a rich set of integrated peripherals, including dual Ethernet controllers, USB 2.0, PCI, and RapidIO interfaces, enabling a wide range of connectivity options.
  • Security: An enhanced security engine supports a variety of algorithms, such as DES, 3DES, AES, SHA-1, and MD5, ensuring secure data communication and protection against unauthorized access.

Applications

The MPC8347EVVAJF is ideal for multiple applications in the networking and communications field, such as:

  • Enterprise and residential gateways
  • Integrated access devices
  • Wireless access points and routers
  • Network attached storage devices
  • Printing and imaging devices

Environmental and Quality Certifications

NXP's commitment to quality and environmental sustainability is evident in the MPC8347EVVAJF, which complies with RoHS and is produced under ISO 9001 certified conditions. The processor is designed to meet the requirements of a wide range of operating temperatures, ensuring reliability and performance in diverse environments.

Conclusion

The NXP MPC8347EVVAJF processor is a versatile and powerful solution for embedded systems, offering a rich feature set and robust security capabilities. Its integration and performance make it an excellent choice for developers looking to create sophisticated networking and computing devices.
