Products specifications

Manufacturer NXP
Win Source Part Number 1235865-PCA9306D
Manufacturer Homepage www.nxp.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name PCA9306
Introduction Date October 20, 2006
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian PCA9306D CAD Model

Description

NXP PCA9306D Dual Bidirectional I2C-Bus and SMBus Voltage-Level Translator

The PCA9306D is a versatile, bidirectional voltage-level translator specifically designed for I2C-Bus and SMBus applications by NXP Semiconductors. This compact device allows for the seamless translation of signals between different voltage levels, enabling communication between devices operating at distinct voltages, ranging from 1.0V to 3.6V on the A-side (Vref1) and 1.8V to 5.5V on the B-side (Vref2).

One of the key features of the PCA9306D is its ability to function without a direction pin. Unlike many other level translators that require a direction control, the PCA9306D automatically detects the signal direction, simplifying the design and reducing the complexity of the system. This makes it an ideal solution for applications where bidirectional data flow is required without the need for any additional external control.

The PCA9306D comes in a small 8-pin TSSOP package, making it a space-efficient choice for modern electronic devices. It is fully specified over the -40°C to +85°C temperature range, ensuring reliable performance across various environmental conditions.

Additionally, the PCA9306D supports hot insertion and offers a lock-up free operation. It is designed with an open-drain configuration, which is essential for multi-master communication environments. It also incorporates a power-off feature on the B-side, which ensures that the device is disabled when Vref2 is held at ground. This feature prevents any unwanted power consumption when the translator is not in use.

Overall, the NXP PCA9306D is an excellent choice for designers looking for a simple, efficient, and reliable way to interface devices with different voltage requirements. Its automatic bidirectional functionality, combined with its compact size and robust performance, makes it a go-to component for a wide range of applications in the consumer electronics, mobile, and telecommunications industries, as well as for computer peripherals and personal computing devices.
