NXP PCF2129T Real-Time Clock (RTC) and Calendar

The PCF2129T from NXP Semiconductors is a highly accurate Real-Time Clock (RTC) and calendar optimized for low power consumption and with a wealth of features designed to cater to a broad range of applications. This integrated circuit is particularly suitable for battery-powered devices where power efficiency is crucial.

Featuring an integrated 32.768 kHz quartz crystal, the PCF2129T offers excellent timekeeping accuracy with minimal external components required. This precision is maintained over a wide temperature range, making the device reliable under various operating conditions. The RTC provides seconds, minutes, hours, day, date, month, and year information, with automatic leap year correction valid up to 2099.

One of the standout features of the PCF2129T is its low power consumption. This is facilitated by a battery switch-over function, which allows the device to automatically switch to battery backup when main power is lost, thus preserving timekeeping without interruption. Additionally, the device has a programmable clock output for peripheral devices, a programmable timer, and a programmable alarm function that can be set to a single event or a periodic event, providing versatility for various application needs.

Communication with the PCF2129T is achieved via an I²C-bus interface, which operates at a frequency of up to 400 kHz. This standard interface ensures easy integration into most microcontroller-based systems. The device also features an aging offset register to compensate for crystal aging, enhancing long-term accuracy.

The PCF2129T is available in a small TSSOP16 package, making it ideal for space-constrained applications. Its broad supply voltage range (1.8 V to 5.5 V) allows for flexibility in system design. With its robust feature set, the NXP PCF2129T is the perfect choice for applications requiring a reliable and precise timekeeping solution, such as smart meters, handheld devices, and industrial systems.
