Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Bulk
Status Obsolete(EOL)
Transistor Polarity NPN
Maximum Current Collector 800mA
VCEO Maximum Collector-Emitter Breakdown Voltage 45V
Max Vce (sat) 700mV @ 50mA, 500mA
Collector Cut-off Current(Max) 100nA
Typical Gain (hFE) (Min) 100 @ 100mA, 1V
Maximum Power Dissipation 625mW
Frequency - Transition 210MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-92-3
Win Source Part Number 200423-BC337G
Family Name BC337
Introduction Date May 25, 2000
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial, Power Management, Safety
Ultra Librarian 3D Model Ultra Librarian BC337G CAD Model

Description

ON Semiconductor BC337G General Purpose Transistor

The BC337G is a versatile NPN bipolar junction transistor (BJT) developed by ON Semiconductor, renowned for its reliability and performance in a wide array of electronic circuits. This general-purpose transistor is commonly utilized in amplification and switching applications, making it an essential component in both hobbyist and commercial projects.

Key Features

  • High Current Gain (hFE): The BC337G offers a high current gain, typically around 100 to 630, which is beneficial for amplification purposes, ensuring a robust signal output for a given input.
  • Maximum Collector Current: It can handle a collector current (IC) up to 800 mA, making it suitable for driving moderate loads in electronic circuits.
  • Voltage Ratings: The transistor has a collector-emitter voltage (VCEO) rating of 45V and a collector-base voltage (VCBO) rating of 50V, providing a good margin for varied applications.
  • Low Voltage Drop: With a low saturation voltage drop, the BC337G ensures efficient operation with minimal power loss, which is crucial for battery-operated devices.
  • TO-92 Package: Enclosed in a compact TO-92 package, the BC337G is designed for through-hole mounting, which is ideal for prototyping and manufacturing with standard PCBs.

Applications

The BC337G transistor is suitable for a myriad of applications including:

  • Audio amplifiers and pre-amplifiers
  • Signal processing
  • Switching circuits
  • Driver stages in hi-fi amplifiers and television circuits
  • Linear amplification and switching

Quality and Reliability

ON Semiconductor ensures that the BC337G meets stringent quality and reliability standards. Each transistor is subjected to rigorous testing and quality control procedures to guarantee optimal performance in your electronic designs. Whether you're developing a simple hobby project or a complex commercial product, the BC337G from ON Semiconductor stands as a reliable choice for your circuitry needs.

Note: Always consult the manufacturer's datasheet for the BC337G to understand the precise specifications and ensure proper usage within your application.
