Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Maximum) 400V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Maximum) at If 1.1V at 2A
Current - Reverse Leakage at Vr 3μA at 400V
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Manufacturer Package 4-SMD, Gull Wing
Supplier Device Package 4-SDIP
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 759151-DF04S2
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian DF04S2 CAD Model

Description

Introducing the DF04S2 Bridge Rectifier from ON Semiconductor

The DF04S2 is a robust bridge rectifier component designed and manufactured by ON Semiconductor, a leader in energy-efficient innovations. This high-quality electronic device is engineered to convert an alternating current (AC) input into a direct current (DC) output, a critical functionality in a wide range of power conversion applications. The DF04S2 is particularly suitable for use in consumer electronics, industrial systems, and other equipment requiring rectification processes.

Key Features and Benefits

  • High Current Capacity: The DF04S2 is capable of handling a maximum repetitive reverse voltage of 400V with a forward current of 1A, making it suitable for moderate power requirements.
  • Low Forward Voltage Drop: With a low forward voltage drop, this device ensures high efficiency, which is essential for maintaining the overall energy efficiency of the system it is integrated into.
  • High Surge Current Capability: It is designed to withstand surge currents, ensuring reliability and robustness in applications where power surges are a concern.
  • Compact Design: The DF04S2 comes in a DFS package, which is known for its small footprint, making it an excellent choice for compact circuit designs where space is at a premium.
  • Wide Operating Temperature Range: This bridge rectifier can operate over a wide temperature range, making it versatile for use in various environments and applications.

Applications

The DF04S2 is ideal for a variety of applications, including:

  • Power supplies
  • AC/DC converters
  • Home appliances
  • Telecommunication equipment
  • Lighting systems

With its reliable performance and ON Semiconductor's commitment to quality, the DF04S2 bridge rectifier is an excellent choice for designers and engineers looking to create efficient and durable power conversion systems. Its ability to handle significant voltage and current, coupled with its compact size, makes it a versatile component that can be integrated into a wide range of electronic devices.

For detailed specifications, application notes, and further information, customers are encouraged to visit ON Semiconductor's official website or contact their local sales representative.
