Products specifications

Win Source Part Number WS1202709-NRVTS260ESFT3G
Win Source Part Number Cross
Manufacturer onsemi
Category Discrete Semiconductor Products Diodes Rectifiers Single Diodes
Series Automotive, AEC-Q101
Package Tape & Reel (TR) Cut Tape (CT)
Product Status Obsolete
Technology Schottky
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 650 mV @ 2 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Ultra Librarian 3D Model Ultra Librarian NRVTS260ESFT3G CAD Model

Description

ON Semiconductor NRVTS260ESFT3G Overview

The NRVTS260ESFT3G is a high-performance Schottky barrier rectifier designed by ON Semiconductor, a leading supplier of semiconductor-based solutions. This rectifier is engineered to provide efficient and reliable operation in a wide range of applications, particularly in power management systems where low forward voltage drop and fast switching are required.

Key Features

  • Low Forward Voltage Drop: The device features a low forward voltage drop, which enhances system efficiency by reducing power loss during operation.
  • High Current Capability: With a high current rating, the NRVTS260ESFT3G is capable of handling significant current loads, making it suitable for high-power applications.
  • Fast Switching Speed: The fast switching speed of this rectifier minimizes switching losses and allows for high-frequency operation, which is critical in modern power supply designs.
  • High Surge Capacity: It has a robust surge handling capability, ensuring the device can withstand transient overvoltage conditions without failure.
  • Low Power Loss: The design of the NRVTS260ESFT3G emphasizes low power loss, contributing to the overall efficiency of the system in which it is used.
  • High-Temperature Operation: The device is rated for operation at high temperatures, making it suitable for demanding environments and applications with minimal cooling options.

Applications

The NRVTS260ESFT3G is ideal for a variety of applications, including:

  • Switch-mode power supplies (SMPS)
  • DC-DC converters
  • Free-wheeling diodes in converters and motor control circuits
  • Power factor correction (PFC) circuits
  • Automotive applications requiring high reliability

Package and Environmental Compliance

The NRVTS260ESFT3G comes in a surface-mount SMB package, which is compact and suitable for automated assembly processes. ON Semiconductor has also ensured that this product is compliant with environmental standards, including RoHS and Pb-Free directives, reflecting the company's commitment to environmental sustainability.

Conclusion

In summary, the NRVTS260ESFT3G from ON Semiconductor is a robust and efficient solution for designers seeking a reliable Schottky barrier rectifier. Its combination of low forward voltage, fast switching, and high-temperature operation makes it a versatile component for a wide range of power management tasks.
