Products specifications

Categories Discrete Semiconductor Products
Estimated Pruduction Lead Time 1 Weeks
Features Diode Array 2 Independent Schottky 20 V 1A Surface Mount 6-SMD (5 Leads), Flat Lead
Manufacturer ON Semiconductor
Package Reel - TR
Speed Fast Recovery =< 500ns, > 200mA (Io)
Mounting Surface Mount
Package 6-SMD (5 Leads), Flat Lead
Case / Package 5-MCPH
Family Name SBS822
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Part Number SBS822-TL-W-ND, SBS822-TL-WOSTR, SBS822-TL-WOSCT, SBS822-TL-WOSDKR
Quantity per package 3000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 933099-SBS822-TL-W
Ultra Librarian 3D Model Ultra Librarian SBS822-TL-W CAD Model

Description

The SBS822-TL-W from ON Semiconductor is a highly efficient and reliable Schottky Barrier Diode designed for voltage clamping applications, protection circuits, and rectification processes. This diode is particularly well-suited for high-frequency inverters, DC-DC converters, and freewheeling diodes in various electronic devices.

Key Features

  • Low Forward Voltage Drop: The SBS822-TL-W boasts a low forward voltage drop, which significantly reduces power loss and improves efficiency in the application it is used.
  • High Surge Capability: This diode can handle high surge currents, making it ideal for applications that may experience unexpected voltage spikes.
  • Compact Package: Encased in a small and flat lead SOD-323FL package, the SBS822-TL-W saves valuable space on the PCB without sacrificing performance.
  • High Reliability: ON Semiconductor's commitment to quality ensures that the SBS822-TL-W diode offers excellent reliability for a long service life in critical applications.
  • Lead-Free and RoHS Compliant: This product adheres to environmental standards, being lead-free and compliant with the Restriction of Hazardous Substances (RoHS) directive.

Applications

The versatile nature of the SBS822-TL-W makes it suitable for a wide range of applications. It is commonly used in:

  • Power management systems
  • Automotive applications
  • Portable devices
  • Switching power supplies
  • DC-DC converters
  • Reverse battery protection circuits

Technical Specifications

  • Package: SOD-323FL
  • Maximum Repetitive Reverse Voltage (Vrrm): 20V
  • Forward Continuous Current (If): 0.2A
  • Maximum Forward Voltage Drop (Vf) at If: 0.385V
  • Operating Temperature Range: -55°C to +150°C

The SBS822-TL-W diode from ON Semiconductor is a testament to the company's dedication to providing components that enhance system performance while minimizing energy consumption. With its robust design and versatile application range, this product is an excellent choice for designers looking to optimize their power management solutions.
