The TIP140G is a high-performance NPN Darlington power transistor designed and manufactured by ON Semiconductor. This robust component is widely used in various electronic applications where high current and voltage capabilities are required. It is especially suited for linear and switching applications.

Key Features

• High Collector-Emitter Voltage: The TIP140G offers a high V_CEO of 60V, making it suitable for operation in high voltage environments.
• High DC Current Gain: With a high h_FE (DC current gain), this transistor can amplify a small input current into a much larger output current, which is ideal for power amplification needs.
• High Collector Current: It can handle a continuous collector current of up to 10A, allowing it to drive heavy loads.
• Complementary PNP Type: The TIP140G has a complementary PNP partner, the TIP145G, which enables the creation of push-pull amplifier configurations.
• Monolithic Construction: The Darlington pair configuration within a single device enhances the current carrying capability and reduces the component count in circuit designs.
• Industry-Standard TO-220 Package: This package is well-known for its good thermal performance, making the TIP140G suitable for applications requiring efficient heat dissipation.

Applications

The TIP140G is versatile and can be used in a variety of applications, including:

• Power regulators
• DC-DC converters
• Motor controllers
• Audio amplifiers
• Switching circuits
• Relay drivers

Reliability and Performance

ON Semiconductor is known for its commitment to quality, and the TIP140G is no exception. The device's robustness and reliability make it an excellent choice for designs that require long-term stability and performance under challenging conditions. Whether you are designing a simple power supply or an intricate motor control system, the TIP140G provides the efficiency and reliability you need.
