Products specifications Report Issue?

Categories Transformers
Manufacturer Pulse Electronics Network
Packaging Tube
Transformer Type T1/E1 (Dual)
Inductance 1.2mH, 1.2mH
Mounting Style SMD
Parts Dimension 0.505" L x 0.280" W (12.83mm x 7.11mm)
Height - Seated (Maximum) 0.245" (6.22mm)
Temperature Range - Operating -40°C ~ 85°C
Weight 0.04 oz (1.14g)
Manufacturer Pack Quantity 40
MSL Level 3 (168 Hours)
Win Source Part Number 1275086-TX1089NL
Manufacturer Homepage www.pulseeng.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TX1089NL CAD Model

Description

The TX1089NL is a through-hole Gigabit Ethernet isolation transformer manufactured by Pulse Electronics. It's designed to provide electrical isolation and common-mode noise rejection in 10/100/1000 Base-T Ethernet applications.

Applications

  • Gigabit Ethernet network interfaces
  • LAN/WAN connectivity
  • Network interface cards (NICs)
  • Motherboard Ethernet ports
  • Industrial Ethernet applications

Features

  • Through-Hole Mounting: Designed for easy installation on printed circuit boards.
  • Gigabit Ethernet Support: Supports data rates up to 1000 Mbps.
  • Electrical Isolation: Provides high-voltage isolation between the Ethernet PHY and the network cable.
  • Common-Mode Noise Rejection: Filters out common-mode noise, improving signal integrity.
  • Low Insertion Loss: Minimizes signal attenuation.
  • High Return Loss: Ensures good impedance matching.

Benefits

  • Enhanced Network Performance: Improved signal integrity due to noise rejection and impedance matching.
  • Electrical Safety: High-voltage isolation protects connected devices and personnel from electrical hazards.
  • Reliable Data Transmission: Minimizes data errors and ensures reliable communication.
  • Easy Integration: Standard through-hole package simplifies design and manufacturing.
  • Compliance: Designed to meet industry standards for Ethernet isolation transformers.

The TX1089NL transformer is a crucial component in Gigabit Ethernet systems, providing the necessary isolation and noise filtering to ensure reliable data transmission. It typically features a compact design and is constructed with high-quality materials to ensure long-term performance. The inductance and turns ratio are carefully designed to match the impedance requirements of Gigabit Ethernet transceivers.

Specifications include a specific inductance value (typically in the microhenry range), a turns ratio optimized for Ethernet applications, and a high isolation voltage rating (typically 1500 Vrms or higher). It is designed to operate over a specified temperature range, ensuring stable performance in various environments.
