Products specifications

RoHS State Request Verification
Manufacturer Rohm Semiconductor
Win Source Part Number 1151140-BA6286
Manufacturer Homepage www.rohm.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BA6286 CAD Model

Description

The BA6286 is a motor driver IC manufactured by Rohm Semiconductor. This IC is designed to drive brushed DC motors in a variety of applications, providing features like forward and reverse control, braking, and overcurrent protection. Its integrated design simplifies the implementation of motor control in various electronic devices.

Applications:

  • Consumer electronics: Used in DVD players, CD players, and other consumer electronic devices with small DC motors.
  • Office equipment: Employed in printers, scanners, and other office automation devices.
  • Toy and hobby applications: Integrated into toy cars, model trains, and other hobby projects.
  • Small robotics: Utilized in small robotic platforms for motor control.
  • Automotive accessories: Found in car audio systems and other automotive accessories requiring motor control.

Features:

  • Forward and reverse control: Allows for bidirectional motor operation.
  • Braking function: Provides a means to quickly stop the motor.
  • Overcurrent protection: Protects the IC and motor from damage due to excessive current.
  • Low voltage operation: Suitable for low-voltage applications.
  • Built-in protection diodes: Protects against inductive kickback from the motor.
  • Compact package: Small form factor for easy integration into various designs.

Benefits:

  • Precise motor control: Enables accurate control of motor speed and direction.
  • Enhanced system reliability: Overcurrent protection prevents damage from excessive current.
  • Simplified design: Integrated protection diodes simplify the external circuitry required.
  • Compact solution: Small size allows for use in space-constrained applications.
  • Cost-effective: Provides a complete motor control solution at a reasonable price.
  • Wide range of applications: Suitable for various low-voltage motor control applications.

Additional Details:

The BA6286 typically operates on a low voltage, as specified in the product datasheet. It requires a few external components, such as decoupling capacitors and resistors, for proper operation. The datasheet provides information on the recommended PCB layout and thermal considerations. The IC's control inputs typically accept standard logic levels, making it easy to interface with microcontrollers and other digital circuits. The output current capability is a crucial parameter to consider when selecting the appropriate motor. The package type and pinout configuration influence the ease of integration into different circuit board designs.
