Products specifications Report Issue?

Manufacturer Rohm Semiconductor
Win Source Part Number 1243450-RN262CS
Manufacturer Homepage www.rohm.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RN262CS CAD Model

Description

The RN262CS is a general-purpose transistor manufactured by Rohm Semiconductor. It's commonly used for switching and amplification in various electronic circuits. Its characteristics make it suitable for a wide range of applications where a small signal transistor is required.

Applications:

  • Switching Circuits: Used as a switch for controlling LEDs, relays, and other small loads.
  • Amplification Circuits: Employed in small signal amplifiers for audio and other low-frequency applications.
  • Inverter Circuits: Can be used in simple inverter circuits.
  • Driver Circuits: Used as a driver for higher-power transistors or other components.
  • Level Shifting: Can be configured for level shifting applications in digital circuits.

Features:

  • NPN Transistor: A general-purpose NPN bipolar junction transistor (BJT).
  • Low Saturation Voltage: Ensures efficient switching performance.
  • High Current Gain (hFE): Provides good amplification capability.
  • Small Signal Operation: Designed for use with small signals.
  • Surface Mount Package: Available in a compact surface mount package (SMT) for efficient board assembly.

Benefits:

  • Versatile Application: Suitable for a wide range of general-purpose applications.
  • Efficient Switching: Low saturation voltage enables efficient switching performance.
  • Good Amplification: High current gain allows for effective amplification.
  • Compact Size: Small surface mount package saves board space.
  • Cost-Effective: Provides a cost-effective solution for switching and amplification needs.

Additional Details:

The RN262CS typically has a collector current (Ic) rating in the tens to hundreds of milliamperes range and a collector-emitter voltage (Vce) rating of around 50V. The exact values can vary based on the specific datasheet revision. It is often used in conjunction with resistors to create biasing networks that set the operating point for amplification. This transistor is frequently found in hobbyist electronics projects and simple circuit designs due to its availability and ease of use. Its small size makes it ideal for densely populated circuit boards.
