PC365NJ0000F Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Sharp Microelectronics
Packaging Reel - TR
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 600% @ 500μA
Rise and Fall Time 60μs, 53μs
Input Type DC
Output Type Darlington
Maximum Output Voltage 35V
Channel Output Current 80mA
Forward Voltage 1.2V
Continuous forward current- Max 10mA
Vce Saturation (Max) 1V
Temperature Range - Operating -30°C to 100°C
Mounting SMD (SMT)
Case / Package 4-Mini-Flat
Win Source Part Number 104964-PC365NJ0000F
Family Name PC365
Introduction Date July 28, 2005
ECCN EAR99
Country of Origin China, Indonesia, Japan
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PC365NJ0000F CAD Model

Description

The PC365NJ0000F is an isolator component manufactured by Sharp Microelectronics.

  • Packaging: reel - TR
  • Mounting: SMD (SMT)
  • Output: Darlington
  • Forward Voltage: 1.2V
  • Isolation Voltage: 3750Vrms
  • DC Current Transfer Ratio (min): 600% @ 500μA
  • Temperature Range: -30°C to 100°C
  • Output Voltage (max): 35V
  • Channel Output Current: 80mA
  • Supply and Demand Status: balanced
