Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Motor Type - AC, DC Brushless DC (BLDC)
Purpose Driver - Fully Integrated, Control and Power Stage
Technology BiCDMOS
Applications General Purpose
Output Current 4A
Supply Voltage - Operating 7 V to 52 V
Voltage - Load 7 V to 52 V
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package PowerSO-20
Win Source Part Number 018266-L6234PD013TR
Family Name L6234
Introduction Date March 12, 1998
ECCN EAR99
Country of Origin United States of America
Halogen Free Compliant
Estimated EOL Date 2025
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian L6234PD013TR CAD Model

Description

STMicroelectronics L6234PD013TR Motor Driver

The L6234PD013TR from STMicroelectronics is a high-performance triple half-bridge driver integrated circuit, designed to drive inductive loads such as relays, solenoids, DC and bipolar stepping motors. It's a versatile solution for various motor driving needs, crafted by one of the leading semiconductor manufacturers known for their innovative and reliable products.

Key Features

  • Operating Voltage Range: The device operates at a voltage range from 8V to 52V, making it suitable for a wide array of applications that require different voltage levels.
  • Output Current Capacity: It can deliver up to 2.8A of output peak current (1.4A DC) to the load, ensuring robust performance for most medium-sized motors.
  • Integrated Protection Features: The L6234PD013TR comes with thermal shutdown, as well as non-dissipative overcurrent protection, which safeguards the IC and the motor from potential damage.
  • Efficient Power SO Package: Housed in a PowerSO20 package, it offers a compact footprint while ensuring efficient heat dissipation and reliable operation even in tight spaces.
  • Cross Conduction Protection: The device includes logic to prevent cross-conduction and shoot-through, enhancing the safety and longevity of the motor driver.

Applications

The L6234PD013TR is particularly adept for driving both uni-polar and bi-polar stepper motors, which makes it an excellent choice for precision control in 3D printers, CNC machines, robotics, and other automated equipment that require precise positioning and movement. Furthermore, it can be used in applications such as home appliances, office automation, and factory automation where robust and reliable motor control is essential.

Design Support

STMicroelectronics provides comprehensive design support for the L6234PD013TR, including detailed datasheets, application notes, and reference designs. This support helps designers to reduce development time and ensure a smooth integration of the motor driver into their projects.

Note: Always consult the latest datasheet and technical resources from STMicroelectronics for the most up-to-date information and ensure that the L6234PD013TR meets the specific requirements of your application.
