The L6920DCTR from STMicroelectronics is a high-efficiency, monolithic, synchronous step-up DC-DC converter specifically designed to operate from a single-cell Lithium-Ion battery or other power sources with similar voltage ranges. Its compact design and advanced features make it an ideal solution for portable applications where energy efficiency and space-saving are critical.
This device is capable of starting up with an input voltage as low as 0.8V and once started, it can continue to operate with an input voltage as low as 1.5V, thanks to its low quiescent current and high efficiency. The L6920DCTR is also equipped with a fixed 1.2MHz switching frequency which allows the use of small, low-profile inductors and capacitors, reducing the overall footprint and bill of materials for the power supply design.
The L6920DCTR boasts an impressive efficiency level of up to 96%, ensuring minimal power loss during the voltage conversion process. This efficiency is maintained over a wide range of output loads, providing consistent performance and extending battery life in portable devices. The device also includes a power-saving shutdown mode, which reduces the quiescent current to less than 1µA, further conserving battery life when the converter is not in use.
Safety and reliability are key aspects of the L6920DCTR's design. It incorporates several protective features, including thermal shutdown, current limiting, and a low-battery comparator that protects the battery from deep discharge. The device comes in a tiny DFN6 (3x3mm) package, making it suitable for space-constrained applications such as mobile phones, PDAs, digital cameras, and other handheld devices.
The L6920DCTR's combination of high efficiency, low quiescent current, and advanced safety features make it a versatile choice for designers looking to optimize their power supply solutions for portable electronics.
For more detailed information, technical specifications, and application notes, please refer to the official STMicroelectronics L6920DCTR datasheet and design resources.
