Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 35V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 2V @ 1A (Typ)
Output Current 1.5A
Operating Supply Current 8mA
PSRR 62dB (120Hz)
Control Protection Features Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 2V @ 1A
Mounting SMD (SMT)
Case / Package D2PAK
Win Source Part Number 018342-L7805CD2T-TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management
Family Name L78
Introduction Date June 21, 2004
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian L7805CD2T-TR CAD Model

Description

STMicroelectronics L7805CD2T-TR Voltage Regulator

The L7805CD2T-TR from STMicroelectronics is a robust, fixed-output voltage regulator designed to deliver a steady 5V DC output from a wider input voltage range. This component is part of STMicroelectronics' L78 series of positive voltage regulators, which are known for their high reliability and ease of use in a variety of electronic applications.

The L7805CD2T-TR is capable of providing up to 1.5A of output current, making it suitable for moderate power requirements. Its thermal overload protection ensures that the device remains safe even under conditions that could potentially lead to overheating. Additionally, the regulator features short-circuit protection and output transition SOA protection, further enhancing its stability and longevity.

One of the key advantages of this voltage regulator is its low dropout voltage, which allows it to operate efficiently even when the input voltage is close to the output voltage. This makes it an excellent choice for battery-powered devices, where maximizing battery life is essential.

The device comes in a TO-263 (D2PAK) surface-mount package, which is ideal for space-constrained applications. The compact form factor allows for efficient use of PCB real estate, while still providing excellent power dissipation characteristics.

Typical applications for the L7805CD2T-TR include use in power supplies for consumer electronics, computer hardware, and other microprocessor-based systems that require a stable 5V supply. Its robust design also makes it suitable for industrial and automotive applications where reliability is paramount.

Overall, the STMicroelectronics L7805CD2T-TR voltage regulator is a versatile and dependable choice for designers looking to ensure a stable power supply in their circuits. With its combination of protection features, high current capability, and efficient operation, it stands as a go-to component for a wide array of 5V power supply needs.

For detailed specifications and application notes, designers are encouraged to consult the datasheet provided by STMicroelectronics, which offers comprehensive guidance on how to integrate the L7805CD2T-TR into their designs.
