Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tray
Applications Automotive
Supply Current 4μA
Supply Voltage (V) 5V ~ 28V
Temperature Range - Operating -40°C ~ 150°C
Mounting Style SMD
Manufacturer Package 64-TQFP Exposed Pad
Supplier Device Package 64-TQFP
Family Part Number L99DZ80
Manufacturer Pack Quantity 160
MSL Level 3 (168 Hours)
Win Source Part Number 1194732-L99DZ80EP
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian L99DZ80EP CAD Model

Description

The L99DZ80EP, from the renowned semiconductor manufacturer STMicroelectronics, is an advanced motor driver that's designed to meet the rigorous demands of automotive and industrial applications. This high-performance device is engineered to drive brushed DC motors and stepper motors with exceptional efficiency and precision.

Key Features

  • High-Integration: The L99DZ80EP integrates multiple features such as a voltage regulator, dual full-bridge drivers, and a serial communication interface, reducing the need for external components and simplifying the design process.
  • Flexibility: With its capability to handle a wide range of supply voltages, from 7V up to 28V, this driver is versatile and suitable for a variety of motor driving scenarios.
  • Protection Mechanisms: It comes with an array of protection features including over-current, over-temperature, and under-voltage shutdown, ensuring the safety and longevity of the application.
  • Diagnostic Functions: The L99DZ80EP offers advanced diagnostic capabilities that allow for real-time monitoring of system status, aiding in fault detection and system maintenance.
  • Serial Interface: The inclusion of a serial peripheral interface (SPI) facilitates communication with microcontrollers, allowing for control and feedback in complex systems.

Applications

The L99DZ80EP is an ideal solution for a range of applications, particularly in the automotive sector, where reliability and performance are critical. It can be used for:

  • Automotive engine control systems
  • Body control modules
  • Automotive HVAC systems
  • Industrial automation and robotics

Technical Specifications

With its robust design and advanced technical specifications, the L99DZ80EP stands out as a top choice for developers and engineers. It supports a peak current output of up to 10A, and its operational temperature range spans from -40°C to 150°C, making it suitable for harsh environments.

Conclusion

STMicroelectronics' L99DZ80EP is a testament to the company's commitment to providing high-quality, integrated solutions for motor control. Whether for automotive or industrial use, this motor driver offers the performance, flexibility, and reliability that modern applications demand.
