Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer STMicroelectronics
Packaging Reel - TR
Type Clock/Calendar
Features Alarm, Leap Year, Square Wave Output, SRAM, Watchdog Timer
Memory Size 7B
Date Format YY-MM-DD-dd
Interface I2C, 2-Wire Serial
Operating Supply Voltage 3 V ~ 5.5 V
Voltage - Supply, Battery 2 V ~ 5.5 V
Current - Timekeeping (Maximum) 10μA @ 5.5V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 16-VQFN Exposed Pad
Manufacturer Package 16-QFN (4x4)
Win Source Part Number 1210583-M41T83SQA6F
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Balance
Family Name M41T83
Introduction Date May 08, 2007
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian M41T83SQA6F CAD Model

Description

The M41T83SQA6F is a low-power serial real-time clock (RTC) with a built-in 32.768 kHz oscillator from the renowned semiconductor manufacturer, STMicroelectronics. Designed for high precision and reliability, this RTC provides a comprehensive feature set that makes it ideal for a wide range of applications in consumer, industrial, and telematics.

Key Features

  • Accurate Timekeeping: Integrated crystal oscillator ensures high accuracy timekeeping.
  • Low Power Consumption: Optimized for battery-powered applications, ensuring minimal power drain.
  • Serial Interface: I2C serial interface for easy integration with most microcontrollers.
  • Calendar: Full calendar with century flag that is valid until the year 2099.
  • Alarms: Two programmable time-of-day alarms and one programmable square-wave output.
  • Watchdog Timer: Programmable watchdog timer for system reset in case of failure.
  • Counters: Counters for seconds, minutes, hours, day, date, month, year, and century.
  • Temperature Compensation: On-chip temperature compensation for improved accuracy.

Applications

The versatility of the M41T83SQA6F makes it suitable for various applications including:

  • Embedded Systems
  • Utility Meters
  • POS Terminals
  • Consumer Electronics
  • Industrial Controllers
  • Telematics and Networking Equipment

Additional Information

The M41T83SQA6F comes in an 8-pin SOIC package, making it compact and easy to integrate into system designs. Its built-in crystal means fewer external components are required, simplifying the design and reducing overall system costs. With its robust feature set and STMicroelectronics' commitment to quality, the M41T83SQA6F is a reliable choice for maintaining accurate time in your electronic projects.

For detailed technical specifications, application notes, and support resources, visit the STMicroelectronics official product page.
