Products specifications Report Issue?

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 12.8V
Minimum Breakdown Voltage 14.3V
Max Clamping Voltage 27.2V
Peak Pulse Current(Ippm) 147A (8/20μs)
Power Dissipation - Pd 600W
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SMB (DO-214AA)
Win Source Part Number 094993-SM6T15A
Family Name SM6T15A
Introduction Date July 04, 2006
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Defence, Military & Aerospace, Power Management, Industrial
Ultra Librarian 3D Model Ultra Librarian SM6T15A CAD Model

Description

STMicroelectronics SM6T15A Transil™ TVS Diode

The SM6T15A from STMicroelectronics is a Transil™ transient voltage suppression (TVS) diode designed to protect sensitive electronic equipment from voltage transients induced by load dump and other transient voltage events. This high-quality TVS diode is specifically engineered to dissipate high transient power and clamp voltage to a safe level, ensuring the protection of integrated circuits and other sensitive components.

Key Features

  • Stand-off Voltage: The SM6T15A has a stand-off voltage of 15V, making it suitable for a range of applications where this voltage level is common.
  • Peak Pulse Power: It offers a peak pulse power dissipation of 600W (10/1000μs surge), able to handle significant power spikes.
  • Low Clamping Voltage: With a low clamping voltage, the SM6T15A ensures that the voltage seen by the protected component does not exceed a safe level during transient conditions.
  • Fast Response Time: The device responds to overvoltage events in less than 1 picosecond, providing immediate protection for connected electronics.
  • Unidirectional Protection: This TVS diode offers unidirectional transient voltage suppression, ideal for DC power line applications.
  • Compliance: It complies with the following standards: IEC 61000-4-2 (ESD), IEC 61000-4-4 (EFT), and IEC 61000-4-5 (Surge).

Applications

The SM6T15A is suitable for a wide variety of applications where electronic components need to be protected from electrical surges and spikes. These include:

  • Power supply lines
  • Industrial systems
  • Telecommunication devices
  • Consumer electronics
  • Automotive electronics
  • Computer systems

Quality and Reliability

STMicroelectronics is known for its commitment to quality and the SM6T15A is no exception. It is manufactured to high standards, ensuring reliability and performance in even the most demanding situations. The device's robust design allows it to withstand harsh industrial environments while continuing to provide the highest level of protection.

For detailed specifications and application notes, or to order samples, please visit the STMicroelectronics website or contact your local STMicroelectronics sales office.
