Products specifications

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr STMicroelectronics
Series Automotive, AEC-Q101, SM6TY, TRANSIL™
Package Tape & Reel
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 25.6V
Voltage - Breakdown (Min) 28.5V
Voltage - Clamping (Max) @ Ipp 53.5V
Current - Peak Pulse (10/1000µs) 75A (8/20µs)
Power - Peak Pulse 600W
Power Line Protection No
Applications Automotive
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Supplier Device Package SMB (DO-214AA)
Base Product Number SM6T30
Standard Package 2,500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 668405-SM6T30CAY
Ultra Librarian 3D Model Ultra Librarian SM6T30CAY CAD Model

Description

Introducing the SM6T30CAY Transil™ TVS Diode from STMicroelectronics

The SM6T30CAY is a high-performance transient voltage suppression (TVS) diode designed by STMicroelectronics to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events. This robust component is part of the Transil™ series, which is renowned for its ability to safeguard circuits against extreme voltage spikes while maintaining a low clamping voltage.

With its bidirectional transient voltage suppression capabilities, the SM6T30CAY is particularly suitable for applications that require a high level of protection on AC or bipolar lines. This makes it an ideal choice for a wide range of products, including consumer electronics, industrial systems, and telecommunications infrastructure.

Key Features of the SM6T30CAY

  • Stand-off Voltage: The device is designed to withstand a stand-off voltage of 30V, providing a high degree of protection for sensitive components.
  • Peak Pulse Power: It offers a peak pulse power dissipation of 600W (10/1000μs), ensuring that even significant transient power spikes are effectively managed.
  • Low Clamping Voltage: The low clamping voltage of this TVS diode ensures that excess voltage is quickly and effectively clamped, minimizing the risk to connected components.
  • Package: Housed in a SMB (DO-214AA) package, the SM6T30CAY is compact and suitable for high-density circuit board designs.
  • Temperature Range: It operates within a wide temperature range from -40°C to +150°C, providing reliable protection in various operating conditions.
  • Compliance: This device meets the IEC 61000-4-5 standard for surge immunity, ensuring compliance with international safety requirements.

Applications of the SM6T30CAY

The versatile nature of the SM6T30CAY makes it a perfect fit for a multitude of applications where transient voltage protection is critical. Its use cases include:

  • Power supply lines
  • AC/DC applications
  • Telecommunication systems
  • Industrial electronics
  • Microprocessor-based equipment
  • Computer systems

With its combination of high surge capability, fast response time, and low clamping voltage, the SM6T30CAY from STMicroelectronics is an essential component for designers looking to enhance the durability and reliability of their electronic systems against transient voltage events.
