Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 44 Weeks
Features 1/1 Transceiver Half RS422, RS485 8-SOIC
Manufacturer STMicroelectronics
Series Automotive, AEC-Q100
Package Reel - TR
Family Name ST3485
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 497-16693-2, 497-16693-1, 497-16693-6
Quantity per package 2500
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 848631-ST3485EIDT
Ultra Librarian 3D Model Ultra Librarian ST3485EIDT CAD Model

Description

ST3485EIDT: High-Speed Transceiver from STMicroelectronics

The ST3485EIDT is a robust, high-speed transceiver module designed by STMicroelectronics, a leader in the semiconductor industry. This device is part of ST's interface IC portfolio and is specifically tailored for bidirectional communication on RS-485 and RS-422 networks. The ST3485EIDT is engineered to provide efficient data transmission over long distances and in electrically noisy environments, making it an ideal solution for industrial, networking, and automation applications.

Featuring a differential line driver and a receiver that operate from a single 5V power supply, the ST3485EIDT is capable of transmitting data rates up to 12 Mbps. This high-speed capability ensures that it can support the demands of high-performance serial communication interfaces. The transceiver is compliant with the EIA/TIA-485 standard, which guarantees interoperability with other standard RS-485 devices.

The ST3485EIDT offers several protective features that make it particularly resilient in harsh conditions. It has an extended common-mode range of -7V to +12V, which exceeds the industry standard, and it is protected against ±15 kV human body model electrostatic discharge (ESD) on the transceiver interface. This level of protection is critical in preventing damage during handling and operation, thereby enhancing the reliability and longevity of the product.

One of the key attributes of the ST3485EIDT is its low-power consumption. The device includes a low-power shutdown mode that significantly reduces power usage when the transceiver is inactive. Additionally, it offers a driver tri-state function, allowing the output to be disabled, which is vital for multi-point applications on a shared bus.

To facilitate easy integration into various designs, the ST3485EIDT is available in a compact SO-8 package. This small footprint allows for a more efficient use of PCB space, making it suitable for space-constrained applications. The device is also characterized for operation from -40°C to 85°C, ensuring reliable performance across a wide range of environmental conditions.

In summary, the ST3485EIDT from STMicroelectronics is a high-speed, robust, and reliable transceiver that meets the stringent requirements of modern industrial and networking applications. Its protective features, low-power operation, and compliance with industry standards make it a versatile and essential component in RS-485/RS-422 communication systems.
