Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr STMicroelectronics
Package Bulk
Product Status Obsolete
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 3.3V
Current - Output 1.5A
Voltage - Input 4.4V ~ 25V
Regulator Topology Buck
Frequency - Switching 250kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part L5972D
Other Names 497-12915,STEVALISA089V1,-497-12915
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284214-STEVAL-ISA089V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA089V1 CAD Model

Description

The STEVAL-ISA089V1 is an innovative product from STMicroelectronics, designed as a demonstration and development platform for a high-efficiency, step-down monolithic switching regulator known as the VIPer17. The VIPer17 is a compact, offline switched-mode power supply (SMPS) with an integrated 800V avalanche-rugged power MOSFET, which makes it ideal for a wide range of applications.

This evaluation board is particularly tailored for providing a 12V output voltage with a maximum load current of 1A, making it suitable for use in auxiliary power supplies. The primary target applications for this product are industrial control systems, home appliances, and other low-power utility circuits where reliability and efficiency are paramount.

Key Features

  • Integrated Features: The VIPer17 integrates PWM control, a high-voltage startup circuit, sense FET, error amplifier, and various protection features into a single chip, simplifying design and reducing component count.
  • High Efficiency: With its advanced design, the STEVAL-ISA089V1 achieves high efficiency, thus reducing energy consumption and heat dissipation.
  • Protection Mechanisms: The board includes overvoltage, overload, and thermal protection, ensuring safe operation under various conditions.
  • Compact Size: The small form factor of the evaluation board is ideal for space-constrained applications.
  • Easy-to-use: It comes with a ready-to-use layout that simplifies the testing and evaluation process, allowing designers to quickly integrate it into their projects.

Applications

  • Industrial control systems
  • Home appliances
  • Standby power supplies
  • Auxiliary power supplies

The STEVAL-ISA089V1 is a testament to STMicroelectronics' commitment to providing innovative, efficient, and reliable solutions for power management challenges. By choosing the STEVAL-ISA089V1 for your designs, you can expect a high level of performance, durability, and ease of integration, making it an excellent choice for developers and engineers looking to enhance their power supply systems.
