Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr STMicroelectronics
Package Bulk
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 5V
Current - Output 1.5A
Voltage - Input 4V ~ 38V
Regulator Topology Buck
Frequency - Switching 500kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part A6986F5V
Base Product Number STEVAL
Other Names 497-16456
Standard Package 1
RoHS Status Not applicable
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284241-STEVAL-ISA189V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA189V1 CAD Model

Description

STEVAL-ISA189V1 - STMicroelectronics Evaluation Board

The STEVAL-ISA189V1 is a highly efficient evaluation board designed by STMicroelectronics, specifically tailored for testing and evaluating the performance of the VIPer11 offline converter. This product is part of ST's VIPerPlus family, known for its energy-saving features and robustness in handling power conversion.

Key Features:

  • Integrated VIPer11: The board is built around the VIPer11 high-voltage converter, which combines a dedicated current mode PWM controller with a high-voltage MDMesh Power MOSFET.
  • Wide Input Voltage Range: It supports a wide input voltage range, making it suitable for a variety of AC/DC power supply applications.
  • Compact Design: The STEVAL-ISA189V1 is designed to be compact, which allows for easy integration into a range of end products without taking up excessive space.
  • Low Standby Power Consumption: It is optimized for low standby power consumption, ensuring energy efficiency even when the connected device is not active.
  • Overcurrent and Overvoltage Protection: The board includes multiple protection features such as overcurrent protection (OCP) and overvoltage protection (OVP), enhancing the safety and longevity of the application.
  • Thermal Shutdown: An integrated thermal shutdown feature prevents the system from overheating, adding an extra layer of protection.
  • Compliance with Safety Standards: The evaluation board meets international safety standards, ensuring reliability and safety in operation.

Applications:

The STEVAL-ISA189V1 is ideal for developing and prototyping a wide array of power supply solutions, including:

  • Home appliances
  • Industrial control systems
  • Standby power supplies
  • Auxiliary power supplies

In summary, the STEVAL-ISA189V1 from STMicroelectronics is a versatile and reliable evaluation board that showcases the capabilities of the VIPer11 offline converter. It provides designers with a convenient platform for creating efficient and compact power solutions suitable for a broad range of electronic products.
