Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - Sensors
Mfr STMicroelectronics
Series MEMS, nano
Package Box
Product Status Obsolete
Sensor Type Accelerometer, 3 Axis
Sensing Range ±2g, 4g, 8g
Interface I2C, SPI
Sensitivity 16LSB/g, 8LSB/g, 4LSB/g
Embedded No
Supplied Contents Board(s)
Utilized IC / Part LIS331DLF
Other Names 497-10492,STEVALMKI090V1
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
HTSUS 8473.30.1180
Win Source Part Number 1283681-STEVAL-MKI090V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-MKI090V1 CAD Model

Description

STEVAL-MKI090V1 Motion MEMS and Environmental Sensor Evaluation Board

The STEVAL-MKI090V1 from STMicroelectronics is a comprehensive evaluation platform designed for testing and prototyping a wide range of motion MEMS (Micro-Electro-Mechanical Systems) and environmental sensors. This versatile board is an essential tool for engineers and developers working on advanced applications in areas such as wearable devices, gaming, navigation, and IoT solutions.

Key Features

  • Integrated suite of sensors including accelerometers, gyroscopes, magnetometers, and environmental sensors for temperature, humidity, and pressure.
  • Designed to interface with ST's sensor fusion software, offering a simplified path to complex motion and environmental data integration.
  • Flexible power supply options, compatible with both USB connection and external batteries, making it suitable for various testing environments.
  • On-board DataFlash memory for data logging, enabling offline analysis of sensor outputs.
  • Comprehensive software ecosystem, including drivers and libraries, to facilitate rapid development and testing.

Applications

The STEVAL-MKI090V1 is ideal for a multitude of applications that require real-time motion tracking or environmental sensing, such as:

  • Consumer electronics: Smartphones, tablets, and VR/AR headsets
  • Health and fitness tracking: Wearables and activity monitors
  • Industrial applications: Navigation systems and drones
  • Home automation: Smart thermostats and weather stations

Technical Specifications

The board is equipped with ST's state-of-the-art sensors, ensuring high performance and reliability:

  • iNEMO inertial module: 3D accelerometer, 3D gyroscope, and 3D magnetometer
  • Environmental sensors for measuring temperature, humidity, and atmospheric pressure
  • High-speed I2C/SPI digital output interface

With the STEVAL-MKI090V1, STMicroelectronics provides a powerful platform for fast and efficient development of sensor-based applications, reducing time-to-market and enabling engineers to focus on innovation and performance optimization.
