Products specifications

Manufacturer STMicroelectronics
Standard Package 50
Category Discrete Semiconductor Products
Family IGBTs - Single
Series PowerMESH
Packaging Tube
Voltage - Collector Emitter Breakdown (Max) 600V
Current - Collector (Ic) (Max) 20A
Current - Collector Pulsed (Icm) 30A
Vce(on) (Max) @ Vge Ic 2.5V @ 15V 5A
Power - Max 65W
Switching Energy 55µJ (on) 85µJ (off)
Input Type Standard
Gate Charge 19nC
Td (on/off) @ 25°C 17ns/72ns
Test Condition 390V 5A 10 Ohm 15V
Reverse Recovery Time (trr) 22ns
Package TO-220-3
Mounting Style Through Hole
Manufacturer Device Package TO-220AB
Catalog Standard IGBTs
Win Source Part Number 066380-STGP10NC60KD
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name STGP10NC60KD
Introduction Date June 14, 2005
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian STGP10NC60KD CAD Model

Description

STGP10NC60KD - IGBT from STMicroelectronics

The STGP10NC60KD is a high-performance IGBT (Insulated Gate Bipolar Transistor) designed and manufactured by STMicroelectronics, a global semiconductor leader. This IGBT is part of STMicroelectronics' PowerMESH™ line, which is known for its excellent trade-off between switching performance and on-state behavior, making it suitable for a wide range of high-power applications.

Key Features:

  • Voltage Rating: The device is rated for a maximum collector-emitter voltage of 600V, providing a comfortable margin for applications requiring high voltage operation.
  • Current Capacity: It can handle a continuous collector current of up to 10A, ensuring it can drive significant loads.
  • Low On-State Voltage Drop: The IGBT features a low on-state voltage drop (Vce(sat)) which enhances its efficiency by minimizing conduction losses.
  • High-Speed Switching: Fast switching characteristics make it ideal for applications that require high switching frequencies.
  • Co-Packaged Diode: It includes an integrated fast recovery diode, which provides protection against reverse voltage transients and reduces the need for external components.

Applications:

The STGP10NC60KD is versatile and can be used in a variety of applications, including:

  • Motor control circuits
  • Inductive heating
  • Uninterruptible Power Supplies (UPS)
  • Power factor correction circuits
  • Switched-mode power supplies

Technical Specifications:

Parameter Value Collector-Emitter Voltage (V<sub>ces) 600V Collector Current (I<sub>c) 10A Power Dissipation (P<sub>d) 45W Operating Junction Temperature (T<sub>j) -40°C to +150°C

Overall, the STGP10NC60KD from STMicroelectronics is a robust and efficient IGBT suitable for high-performance power switching applications. Its advanced features and integrated diode make it a reliable choice for engineers looking to optimize their power management designs.
