Products specifications

Categories Discrete Semiconductor Products
Estimated Pruduction Lead Time 25 Weeks
Features IGBT - 600 V 7.5 A 38 W Through Hole TO-220
Manufacturer STMicroelectronics
Package Tube
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Through Hole
Package TO-220-3
Case / Package TO-220
Family Name STGP3
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Part Number STGP3HF60HD-ND, 497-19154
Quantity per package 50
Popularity High
Supply and Demand Status Balance
Win Source Part Number 935380-STGP3HF60HD
Ultra Librarian 3D Model Ultra Librarian STGP3HF60HD CAD Model

Description

The STGP3HF60HD is a state-of-the-art Insulated Gate Bipolar Transistor (IGBT) developed by STMicroelectronics, one of the industry leaders in semiconductor solutions. This IGBT is designed for high-efficiency and fast-switching applications, making it an ideal choice for a range of power management tasks.

Key Features

  • High-Speed Switching: The STGP3HF60HD offers exceptional switching speeds, which is critical for reducing energy losses during power conversion in inverter and converter systems.
  • High Voltage Capability: With a maximum collector-emitter voltage of 600V, this device can handle significant power levels, suitable for industrial, consumer, and energy applications.
  • Robustness: The device is designed to withstand harsh operating conditions, ensuring reliability and a long operational lifespan.
  • Low On-State Voltage: The low on-state voltage drop helps in minimizing conduction losses and improving the overall efficiency of the system in which it is used.
  • Co-Packaged Diode: The inclusion of a fast and soft recovery anti-parallel diode provides additional functionality and protection for the IGBT, simplifying circuit design.

Applications

The STGP3HF60HD is versatile and can be used in various high-power switching applications. Some of these include:

  • Uninterruptible Power Supplies (UPS)
  • Power Factor Correction (PFC) circuits
  • Induction Heating
  • Motor Drives
  • Welding Equipment

Quality and Support

STMicroelectronics is committed to delivering high-quality products. The STGP3HF60HD is no exception and is backed by comprehensive technical support and documentation. Engineers and designers can rely on this IGBT for efficient, reliable, and high-performance solutions in power management and conversion.

For detailed specifications, application notes, and additional resources, visit the STMicroelectronics website.
