The STM32F767NIH6 is a high-performance microcontroller from STMicroelectronics, designed to offer the best efficiency and versatility in a wide range of applications. This advanced microcontroller is part of the STM32F7 series, which is renowned for its ARM Cortex-M7 core, providing users with a perfect blend of speed and power efficiency.

Key Features

• Core: ARM Cortex-M7 processor, running at a frequency of up to 216 MHz.
• Memory: 2 MB of flash memory and 512+4 KB of RAM, ensuring ample space for complex applications.
• Performance: Boasts a high-performance architecture with a single precision floating point unit, delivering up to 462 DMIPS/1082 CoreMark.

Connectivity and I/O

The STM32F767NIH6 offers a rich set of peripherals for connectivity, including:

• Four I2C interfaces
• Four USARTs and four UARTs
• Three SPIs
• Two CAN interfaces
• Two SAI (Serial Audio Interface)
• SDMMC interface
• USB 2.0 full-speed device/host/OTG controller with on-chip PHY
• USB 2.0 high-speed/full-speed device/host/OTG controller with dedicated DMA, on-chip full-speed PHY and ULPI for external high-speed PHY

Advanced Graphics and Display Features

Equipped with an LCD-TFT controller and support for Chrom-ART Accelerator™, the STM32F767NIH6 is capable of handling complex graphics operations, making it ideal for advanced human-machine interface (HMI) applications.

Enhanced Power Efficiency

With its dynamic voltage scaling and flexible power-saving modes, including a standby mode with RTC and backup registers, the STM32F767NIH6 ensures power efficiency without compromising performance.

Development and Debugging

STMicroelectronics provides extensive development support for the STM32F767NIH6 with a range of software tools, libraries, and real-time operating systems. The microcontroller also features advanced debugging capabilities with the integrated ARM® single-wire debug (SWD) and JTAG interfaces.

Applications

The STM32F767NIH6 is suitable for a diverse array of applications, including industrial control, motor drives, medical equipment, and consumer electronics, thanks to its powerful features and flexible peripheral set.
