Products specifications Report Issue?

Category Integrated Circuits (ICs)>Interface - Drivers, Receivers, Transceivers
Mfr STMicroelectronics
Package Tape & Reel
Type Transceiver
Protocol RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 70 mV
Data Rate 20Mbps
Voltage - Supply 3V ~ 3.6V
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting SMD (SMT)
Package / Case 10-VFDFN Exposed Pad
Supplier Device Package 10-DFN (3x3)
Base Product Number STR485
Other Names 497-STR485ELVQTTR,497-STR485ELVQTDKR,497-STR485ELVQTCT
Standard Package 3,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1261556-STR485ELVQT
Ultra Librarian 3D Model Ultra Librarian STR485ELVQT CAD Model

Description

The STR485ELVQT is a robust, low-power transceiver module designed by STMicroelectronics, a global semiconductor leader known for its cutting-edge technology. This product is a part of the company's extensive range of transceivers and specifically caters to the RS-485 and RS-422 communication standards, which are widely used in industrial, automotive, and telecommunication applications.

Key Features

  • High-Speed Data Transmission: The STR485ELVQT supports data rates up to 20 Mbps, making it suitable for high-speed data communication in complex systems.
  • Low-Power Consumption: With its low-power design, the device operates efficiently, which is crucial for power-sensitive applications.
  • Extended Common-Mode Range: The transceiver can handle common-mode voltages from -7V to +12V, providing reliable data transmission even in electrically noisy environments.
  • Thermal Shutdown Protection: The built-in thermal shutdown feature ensures the device operates within safe temperature ranges, preventing damage from overheating.
  • Fail-Safe Receiver: The receiver remains in a high state when the bus is idle, open, or shorted, enhancing the reliability of the communication system.
  • ESD Protection: The device includes IEC 61000-4-2 ESD protection up to ±8kV, safeguarding the transceiver from electrostatic discharges.

Applications

The STR485ELVQT is versatile and can be used in a variety of applications, including:

  • Industrial control systems
  • Building automation
  • Networked security cameras
  • Point-of-sale terminals
  • Telecommunication infrastructure

Package and Quality

The STR485ELVQT comes in a compact QFN-16 package that is both space-saving and provides good thermal performance. STMicroelectronics adheres to high-quality standards, ensuring that each transceiver is rigorously tested for performance and reliability before it is shipped out to customers.

With its robust feature set and reliable performance, the STR485ELVQT from STMicroelectronics is an excellent choice for designers looking to implement RS-485/RS-422 communication protocols in their systems.
