Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 800V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 1.65V @ 2A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 75ns
Current - Reverse Leakage @ Vr 5μA @ 800V
Mounting SMD (SMT)
Case / Package SMB
Operating Temperature - Junction 175°C (Max)
Win Source Part Number 194801-STTH208U
Family Name STTH208U
Introduction Date February 12, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STTH208U CAD Model

Description

STTH208U Ultrafast Recovery Diode by STMicroelectronics

The STTH208U, manufactured by STMicroelectronics, is a high-performance ultrafast recovery diode specifically designed to meet the rigorous demands of modern electronic applications. This diode is renowned for its exceptional switching speed and minimal power loss during operation, making it an ideal choice for high-efficiency power supplies, inverters, and other power conversion systems.

Key Features

  • High Reverse Voltage Capability: The STTH208U is capable of withstanding reverse voltages up to 800V, providing a robust solution for high-voltage applications.
  • Ultrafast Recovery Time: With an ultrafast recovery time, this diode ensures reduced switching losses, which is critical for high-frequency operations.
  • Low Forward Voltage Drop: The device exhibits a low forward voltage drop, which enhances overall system efficiency by minimizing conduction losses.
  • High Surge Current Capability: Its design allows for a high surge current capability, making it resilient during transient conditions.
  • Soft Recovery Characteristics: The soft recovery behavior of the STTH208U reduces electromagnetic interference (EMI), improving performance in noise-sensitive applications.

Applications

The STTH208U is versatile and can be employed in a variety of applications that require fast and efficient diode performance. Some of the typical applications include:

  • Switch Mode Power Supplies (SMPS)
  • Free-Wheeling Diodes in Inverters
  • Snubber Diodes
  • Power Factor Correction Circuits
  • Automotive Charging Systems

Reliability and Quality

STMicroelectronics is committed to delivering products that meet the highest standards of reliability and quality. The STTH208U is no exception and is constructed to ensure long-term stability and performance under various environmental conditions. It is also compliant with RoHS and other industry standards, reflecting STMicroelectronics' dedication to environmental sustainability.

In summary, the STTH208U ultrafast recovery diode from STMicroelectronics is a superior choice for engineers and designers seeking a diode that combines speed, efficiency, and reliability for their advanced electronic systems.
