Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Output Type Transistor Driver
Purpose Step-Up/Step-Down
Topology Boost, Flyback
Number of Outputs 1
Output Phases 1
Supply Voltage - Operating 7.6 V to 30 V
Frequency - Switching 250kHz
Duty Cycle (Max) 48%
Synchronous Rectifier No
Clock Sync No
Control Features Frequency Control
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package 8-SO
Win Source Part Number 035704-UC3845BD1013TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Industrial
Family Name UC3845B
Introduction Date March 04, 1999
ECCN EAR99
Country of Origin Morocco
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian UC3845BD1013TR CAD Model

Description

Product Overview: UC3845BD1013TR

The UC3845BD1013TR is a high-performance current mode PWM controller manufactured by STMicroelectronics, a leader in the semiconductor industry. This integrated circuit is designed to facilitate the development of power supplies and DC-DC converters across a wide range of applications. Its robust design and advanced features make it an excellent choice for engineers looking to create efficient and reliable power management solutions.

Key Features

  • High-Frequency Operation: The UC3845BD1013TR operates at a frequency up to 500 kHz, allowing for smaller sized components and reduced power losses, which is critical for compact and energy-efficient power supply designs.
  • Current Mode Control: This control method provides superior transient response, simplified loop compensation, and inherent pulse-by-pulse current limiting, enhancing the overall performance and safety of the power supply.
  • Trimmed Oscillator Discharge Current: The oscillator discharge current is trimmed to ensure precise duty cycle clamping, which helps to maintain stability and control over the power supply output.
  • Automatic Feed Forward Compensation: This feature helps to maintain stable operation despite variations in input voltage, which is particularly useful in environments with fluctuating power sources.
  • Low Startup and Operating Current: The device's low startup current minimizes power consumption during the initial power-up phase, while the low operating current contributes to the overall efficiency of the power supply during normal operation.

Applications

The UC3845BD1013TR is versatile and can be used in a variety of applications, including:

  • Switching power supplies
  • DC-DC converters
  • Battery chargers
  • Power factor correction circuits
  • LED drivers
  • Telecom and data communication power systems

Package and Quality

STMicroelectronics packages the UC3845BD1013TR in a convenient SO-8 package, making it easy to integrate into printed circuit boards. The product is available in tape and reel format, which facilitates automated assembly processes. Furthermore, the device meets stringent quality standards, ensuring reliability and performance in even the most demanding applications.

In conclusion, the UC3845BD1013TR by STMicroelectronics is a sophisticated and adaptable PWM controller suitable for a broad range of power management applications. Its high-frequency operation, current mode control, and other advanced features enable designers to create compact, efficient, and high-performance power supplies.
