STMicroelectronics VN800STR-E High Side Driver

The VN800STR-E is a sophisticated high side driver from STMicroelectronics, designed to deliver robust performance in driving inductive, resistive, or capacitive loads with high efficiency. This integrated circuit is part of ST's VIPower family and is particularly suited for automotive applications, including but not limited to, driving lamps, solenoids, or motors.

Encased in a compact SO-8 package, the VN800STR-E is engineered to handle a wide range of operating voltages, from 5.5V to 36V, making it versatile for various electrical environments. The device is characterized by its on-state resistance of 80 mOhms, which ensures minimal voltage drop and power dissipation when conducting high currents, thereby enhancing overall system reliability.

This high side driver features an array of built-in protective functions, which include overcurrent protection, overtemperature shutdown, load dump voltage surge protection, and active clamp. These features are crucial for safeguarding the device and the load in the unpredictable conditions often encountered in automotive settings. Additionally, the VN800STR-E incorporates diagnostic functions that provide feedback on the status of the device and the load, enabling advanced control and monitoring capabilities.

The VN800STR-E is not only robust but also user-friendly. It offers a CMOS compatible input and can be directly interfaced with microcontrollers, making it easy to integrate into modern automotive electronic systems. Its fast demagnetization of inductive loads is also a standout feature, ensuring that the device can handle the inductive kickback effectively, which is common in automotive applications.

In summary, the VN800STR-E from STMicroelectronics is a high-performance high side driver that combines efficiency, reliability, and advanced protection features. It is an ideal choice for designers looking to implement a dependable driver in automotive or similar demanding applications where high current handling and robust protection are paramount.
