The VND5160JTR-E is a state-of-the-art, double channel high-side driver manufactured by STMicroelectronics, designed to deliver robust performance for automotive and industrial applications. This advanced component is part of the VIPower M0-7 series and is specifically engineered to drive automotive loads with enhanced efficiency and reliability.

Key Features

• High-Side Switch Type: The VND5160JTR-E is a high-side driver, which allows it to efficiently control the current flow to the load without the ground connection issues that can be associated with low-side drivers.
• Dual Independent Channels: With two independent channels, it can control two separate loads, making it versatile for a variety of applications.
• Current Limitation: Each channel has active current limitation to protect the device and the load from overcurrent conditions.
• Thermal Shutdown: An integrated thermal shutdown feature ensures the device operates within safe temperature limits, preventing thermal damage.
• Status Feedback: Diagnostic feedback is available through status pins, which can be used to monitor the health and functioning of the driver.
• Load Dump Protection: The VND5160JTR-E is designed to withstand voltage transients, such as load dump in automotive environments, enhancing its durability and lifespan.

Applications

The VND5160JTR-E is ideal for a wide range of applications within the automotive sector, including but not limited to:

• Automotive interior lights
• Engine management systems
• Body control modules
• Automotive peripheral controls

Quality and Reliability

STMicroelectronics is known for its commitment to quality, and the VND5160JTR-E is no exception. It is qualified under AEC-Q100, which is a critical standard for automotive integrated circuits, ensuring that the component meets the stringent requirements of the automotive industry. The device is also designed with robust ESD (Electrostatic Discharge) protection, safeguarding it from unexpected electrical spikes.

Package and Environmental Compliance

The VND5160JTR-E comes in a compact PowerSSO-36 package, which is designed for space-efficient applications. It is also compliant with RoHS and is lead-free, making it an environmentally conscious choice for electronic designs.
