Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Obsolete(EOL)
Switch Type General Purpose
Number of Outputs 2
Output Type N-Channel
Voltage - Load 5.5 V to 36 V
Supply Voltage - Operating Not Required
Current - Output (Max) 6A
Rds On (Typ) 60 mOhm (Max)
Input Type Non-Inverting
Fault Protection Current Limiting (Fixed), Over Temperature, Over Voltage
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package 10-PowerSO
Win Source Part Number 036447-VND830ASP13TR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VND830ASP13TR CAD Model

Description

The VND830ASP13TR from STMicroelectronics is an advanced high-side driver designed to meet the stringent requirements of automotive applications. This device is part of the VIPower™ M0-3 series and is particularly suitable for driving high-power loads with high inrush current, such as automotive bulbs, solenoids, and motors.

Key Features

  • Integrated Dual Channel: The VND830ASP13TR provides two independent high-side drivers in a single package, allowing compact and efficient designs.
  • High Voltage Capability: With an operating voltage range of 5.5V to 36V, this driver is versatile and capable of handling the variations commonly found in automotive electrical systems.
  • High Current Rating: It can deliver a continuous current of up to 30A, making it suitable for high-power applications.
  • Thermal Shutdown: A built-in thermal shutdown feature protects the device and the load in the event of overheating.
  • Load Current Limitation: This safety feature prevents damage to the driver and the load by limiting the current in case of a fault condition.
  • Overvoltage Clamp: An overvoltage clamp protects sensitive loads against transient voltage spikes.
  • Status Feedback: Diagnostic feedback is available to monitor the status of the driver and the load, enhancing system reliability.

Applications

The VND830ASP13TR is ideal for a variety of automotive applications, including but not limited to:

  • Automotive interior and exterior lighting
  • Engine and transmission control units
  • Body control modules
  • Motor and valve control systems

Package and Quality

The device is offered in a PowerSSO-16 package, which is designed to optimize the thermal performance and minimize the PCB space required. The VND830ASP13TR is also AEC-Q100 qualified, ensuring its reliability and performance under the harsh conditions typical of automotive environments.

Conclusion

With its robust design, comprehensive protection features, and diagnostic capabilities, the VND830ASP13TR from STMicroelectronics represents a reliable and efficient solution for driving high-side loads in automotive applications. Its integration of dual channels and high current capabilities make it a versatile choice for designers looking to enhance system performance and safety.
