Same model may have multiple batches, images only for reference.
HRG3216Q-22R0-D-T1 Susumu
Same model may have multiple batches, images only for reference.

HRG3216Q-22R0-D-T1

Part No HRG3216Q-22R0-D-T1
Manufacturer Susumu
Catalog Chip Resistor - Surface Mount
Description RES SMD 22 OHM 0.5% 1W 1206
Datasheet
HRG3216Q-22R0-D-T1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Win Source Part Number WS1304269-HRG3216Q-22R0-D-T1
Manufacturer Susumu
Category Resistors- Chip Resistor - Surface Mount
Packaging  Tape & Reel (TR) Cut Tape (CT)
Part Status Active
Resistance (Ohms) 22 Ohms
Tolerance ±0.5%
Power (Watts) 1W
Composition Thin Film
Temperature Coefficient (Typ) ±50ppm/°C
Operating Temperature -55°C ~ 155°C
Package / Case 1206 (3216 Metric)
Ultra Librarian 3D Model Ultra Librarian HRG3216Q-22R0-D-T1 CAD Model

Description

・ Wider bottom terminal enabling higher power capability (short side terminal)
・Significantly larger power handling capability than existing same size resistors
・Size: 3216, Power rating: 1.0W, Resistance range: 10 ~ 100KΩ
・ Precision resistance tolerance: ±0.1%, very small TCR: ±25ppm/°C
・Thin film structure enabling low noise and anti-sulfur
