CD4015BE Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Logic Type Shift Register
Output Type Push-Pull
Number of Elements 2
Number of Bits per Element 4
Purpose Serial to Parallel
Supply Voltage - Operating 3 V to 18 V
Temperature Range - Operating -55°C to 125°C
Mounting Through Hole
Case / Package 16-PDIP
Win Source Part Number 006157-CD4015BE
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Signal Processing
Ultra Librarian 3D Model Ultra Librarian CD4015BE CAD Model

Description

CD4015BE

The CD4015BE is another variant of the dual 4-bit static shift register, designed for demanding digital applications. It is known for its high operational reliability and versatility in handling diverse tasks by processing data across two parallel 4-bit channels.

  • Applications:
    • Data reception and data flow control
    • Delay line applications
    • Signal modulation systems
  • Features and Benefits:
    • Two independent shift register channels
    • Superior noise margin
    • Highly compatible across varied voltage levels from 3V to 15V
  • Additional Details:
    • Temperature Range: -55°C to 125°C
    • Package: Through-hole
