CD4046BE Texas Instruments CD4046BE Real Image CD4046BE Real Image
Same model may have multiple batches, images only for reference.
CD4046BE Texas Instruments CD4046BE Real Image CD4046BE Real Image
CD4046BE Texas Instruments CD4046BE Real Image CD4046BE Real Image
Same model may have multiple batches, images only for reference.

CD4046BE

Part No CD4046BE
Manufacturer Texas Instruments
Catalog Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description IC PHASE-LOCK LOOP MCPWR 16-DIP
Datasheet
CD4046BE Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Type Phase Lock Loop (PLL)
Input CMOS
Output CMOS
Number of Circuits 1
Maximum Input Frequency 2.4MHz
Supply Voltage - Operating 3 V to 18 V
Temperature Range - Operating -55°C to 125°C
Mounting Through Hole
Case / Package 16-PDIP
Win Source Part Number 006176-CD4046BE
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Signal Processing
Family Name CD4046
Introduction Date January 01, 2002
ECCN EAR99
Country of Origin Malaysia, Malaysia, Mexico, Mexico
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian CD4046BE CAD Model

Description

CD4046BE Product Description

The CD4046BE is a highly efficient PLL IC, known for its simplicity and effectiveness in frequency synthesis and modulation tasks. This component is designed to enhance the performance of electronic systems.

Features and Benefits

  • Ease of use: Simplified circuit designs for quick implementation.
  • Integrated components: Features an onboard VCO and phase comparator.
  • Wide operational voltage: Functions effectively across a broad range of power supply voltages.

Applications

  • Phase modulation systems
  • Frequency modulation in audio systems
  • Signal processing for digital communications

The CD4046BE is valued for its reliability and flexibility across various electronic applications.
