Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube
Reference Type Shunt
Output Type Fixed
Min/Fixed Output Voltage 2.5V
Output Current 10mA
Tolerance ±0.4%
Temperature Coefficient 25ppm/°C
Current - Cathode 400μA
Temperature Range - Operating 0°C ~ 70°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SOIC
Family Part Number LT1009
Manufacturer Pack Quantity 75
MSL Level 1 (Unlimited)
Win Source Part Number 1204678-LT1009CD
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Signal Processing, Power Management
Ultra Librarian 3D Model Ultra Librarian LT1009CD CAD Model

Description

The LT1009CD is a precision voltage reference component manufactured by Texas Instruments, renowned for its stability and reliability across a wide range of applications. This precision device is designed to offer a fixed 2.5V output voltage with a tight tolerance, making it an ideal choice for high-performance analog circuits.

Key Features

  • Output Voltage: The LT1009CD provides a stable 2.5V output which is crucial for accurate data conversion in analog-to-digital and digital-to-analog converters, as well as other sensitive electronic applications.
  • Low Temperature Coefficient: This device boasts an impressive low temperature coefficient, ensuring minimal deviation in output voltage over a wide temperature range, which is vital for consistent performance in varying environmental conditions.
  • High Stability: With long-term stability, the LT1009CD ensures that the output voltage remains consistent over time, making it reliable for critical applications that demand precision over extended periods.
  • Low Noise: It exhibits low noise characteristics, which is essential for maintaining signal integrity in high-fidelity audio applications and sensitive measurement equipment.
  • Wide Operating Current Range: The device operates over a broad current range, providing designers with flexibility in a variety of circuit configurations.

Applications

The LT1009CD is suitable for a diverse array of applications, including but not limited to:

  • Precision data systems
  • High-resolution analog-to-digital converters
  • Instrumentation
  • Portable test equipment
  • Battery-powered devices
  • Industrial process control systems

Quality and Reliability

As with all Texas Instruments products, the LT1009CD is built to meet the highest industry standards of quality and reliability. It is available in an SO-8 package, making it suitable for surface-mount technology (SMT) and compact PCB designs. Whether for professional, industrial, or educational use, the LT1009CD from Texas Instruments stands as a benchmark for voltage reference solutions, providing precision, stability, and reliability where it matters most.
