Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Translator Type Voltage Level
Channel Type Bidirectional
Number of Circuits 1
Channels per Circuit 2
Voltage - VCCA 1.2V to 3.3V
Voltage - VCCB 1.8V to 5.5V
Output Type Open Drain, Push-Pull
Temperature Range - Operating -40°C to 85°C (TA)
Features Auto-Direction Sensing
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 209662-PCA9306DCURG4
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PCA9306DCURG4 CAD Model

Description

The PCA9306DCURG4 from Texas Instruments is a highly sophisticated, advanced level shift IC (Integrated Circuit) that is designed to provide optimal performance in a wide range of applications.

  • Product: PCA9306DCURG4
  • Manufacturer: Texas Instruments
  • Type: I2C and SMBus, bidirectional voltage-level translator with an enable (EN) input
  • VREF1 Operation: 1.2-V to 3.3-V
  • VREF2 Operation: 1.8-V to 5.5-V
  • VCC Offset Voltage: Low 50-mV
  • Propagation Delay: Maximum of 5 ns
  • Design: Voltage level translation without a direction pin
  • Feature: Power-down function
  • Package: Ultra-small 8-pin DSBGA package
  • Compliance: RoHS compliant and free from lead, halogens and Antimony
  • Standard: Meets the requirements of the JEDEC standard No. 20C
