AM1P-0505SZ Real Image
Same model may have multiple batches, images only for reference.

AM1P-0505SZ

Part No AM1P-0505SZ
Manufacturer AIMTEC
Catalog PMIC - Voltage Regulators - Linear + Switching
Description DC DC CONVERTER 5V 1W  /  Isolated Module DC DC Converter 1 Output 5V 200mA 4.5V - 5.5V Input
Datasheet
AM1P-0505SZ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>DC DC Converters
Mfr aimtec
Series AM1P-Z (1W)
Package Tube
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 5.5V
Voltage - Output 1 5V
Current - Output (Max) 200mA
Power (Watts) 1 W
Voltage - Isolation 1 kV
Applications ITE (Commercial)
Temperature Range - Operating -40°C ~ 85°C
Efficiency 79%
Mounting Type Through Hole
Package / Case 8-DIP Module, 6 Leads
Dimension 0.50" L x 0.40" W x 0.27" H (12.7mm x 10.2mm x 6.9mm)
Supplier Device Package 8-DIP
Approval Agency CE
Base Product Number AM1P
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Other Names 2374-AM1P-0505SZ,2721-AM1P-0505SZ
Standard Package 1
Win Source Part Number 1230897-AM1P-0505SZ
Ultra Librarian 3D Model Ultra Librarian AM1P-0505SZ CAD Model

Description

The AM1P-0505SZ is a 1W isolated module DC-DC converter designed for use in ITE (commercial) applications.

  • Voltage Isolation: 1 kV
  • Maximum Output Current: 200mA
  • Efficiency: 79%
  • Package: 8-DIP Module
  • Number of Leads: 6
  • Temperature Range: -40°C to 85°C
