HCPL-0201-500E Broadcom Limited HCPL-0201-500E Real Image HCPL-0201-500E real image HCPL-0201-500E real image4539 HCPL-0201-500E Real Image
Same model may have multiple batches, images only for reference.
HCPL-0201-500E Broadcom Limited HCPL-0201-500E Real Image HCPL-0201-500E real image HCPL-0201-500E real image4539 HCPL-0201-500E Real Image
HCPL-0201-500E Broadcom Limited HCPL-0201-500E Real Image HCPL-0201-500E real image HCPL-0201-500E real image4539 HCPL-0201-500E Real Image
Same model may have multiple batches, images only for reference.

HCPL-0201-500E

Part No HCPL-0201-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV PUSH PULL 8SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 1kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Channel Output Current 25mA
Data Rate 5MBd
Propagation Delay tpLH / tpHL (Max) 300ns, 300ns
Rise and Fall Time 30ns, 7ns
Forward Voltage 1.5V
Continuous forward current- Max 10mA
Supply Voltage - Operating 4.5 V to 20 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SO Tall
Win Source Part Number 016821-HCPL-0201-500E
Family Name HCPL-0201
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Philippines, Singapore
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Computers & Computer Peripherals, Signal Processing, Power Management, Industrial
Quantity per package 1,500
Ultra Librarian 3D Model Ultra Librarian HCPL-0201-500E CAD Model

Description

The Broadcom Limited electronic component with Win Source Part Number 016821-HCPL-0201-500E is a high popularity product with sufficient supply and demand.

  • Component Type: Isolator
  • Applications: Computers, computer peripherals, signal processing, power management, and industrial applications
  • Data Rate: 5MBd
  • Channels: 1
  • Isolation Voltage: 3750Vrms
  • Package: 8-SO Tall
  • Mounting: SMD (SMT)
  • Operating Temperature: -40°C to 85°C
  • Common Mode Transient Immunity: 1kV/μs
