Same model may have multiple batches, images only for reference.

SPA10B

Name: SPA10B
Brand: C&K Components
SKU: 1233689
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	SPA10B
Manufacturer	C&K Components
Catalog	DIP Switches
Description	SWITCH SLIDE DIP SPST 10MA 20V / Dip Switch SPST 10 Position Through Hole Slide (Standard) Actuator 10mA 20VDC
Datasheet	SPA10B Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Switches>DIP Switches
Mfr	C&K
Series	SPA
Package	Tube
Circuit	SPST
Number of Positions	10
Current Rating (Amps)	10mA
Voltage Rating	20VDC
Actuator Type	Slide (Standard)
Actuator Level	Flush, Recessed
Contact Material	Beryllium Copper
Contact Finish	Gold
Height Above Board	0.244" (6.20mm)
Mounting Type	Through Hole
Termination Style	PC Pin
Pitch	0.100" (2.54mm), Full
Washable	Yes
Temperature Range - Operating	-30°C ~ 60°C
Body Material	Polyphenylene Sulfide (PPS)
Length	1.142" (29.01mm)
Mechanical Life	1,000 Cycles
Electrical Life	1,000 Cycles
Other Names	CKN9446,*SPA10B
Standard Package	15
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.50.9065
Win Source Part Number	1233689-SPA10B
Ultra Librarian 3D Model	Ultra Librarian SPA10B CAD Model

Alternative Products

Description

The SPA10B DIP switch from C&K is a SPST circuit switch with a through-hole mounting style.

Manufacturer: C&K
Circuit: SPST
Mounting Style: Through-hole
Number of Positions: 10
Pitch: 0.100" (2.54mm)
Termination Style: Full
Contact Finish: Gold
Package: Tube
Voltage Rating: 20VDC
Current Rating: 10mA
Height Above Board: 0.244" (6.20mm)
Length: 1.142" (29.01mm)
Body Material: Polyphenylene Sulfide (PPS)
Electrical Life: 1,000 cycles
Mechanical Life: 1,000 cycles
Actuator Level: Flush and recessed
Washable: Yes
Series: SPA
MSL Level: 1 (unlimited)
REACH: Unaffected
