Products specifications

Type Navigation Switch, 2 - Axis
Actuator Type Tactile (5 Button)
Switch Function 4-Way Directional, Center Select
Output Digital (Mechanical Switch)
Current Rating (Amps) 50mA (DC)
Voltage Rating - DC 12 V
Mounting Type Surface Mount
Termination Style J Lead
Temperature Range - Operating -20°C ~ 70°C
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1555814-JS1300AQ
Ultra Librarian 3D Model Ultra Librarian JS1300AQ CAD Model
