Same model may have multiple batches, images only for reference.
KO119A7302 Real Image
Same model may have multiple batches, images only for reference.

KO119A7302

Part No KO119A7302
Manufacturer E-Switch
Catalog Navigation Switches, Joystick
Description SWITCH KEYLOCK 2POS SPST 4A 125V
Datasheet
KO119A7302 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Switches
Manufacturer E-Switch
Series KO
Circuit SPST
Number of Positions 2
Switch Function Off-On
Contact Timing Not Specified
Current Rating 4A (AC)
Voltage Rating - AC 125V
Actuator Type Flat Key
Key Removable Positions 1 only
Angle of Throw 90°
Contact Material Copper Alloy
Contact Finish Silver
Mounting Panel Mount
Termination Style Solder Lug
Panel Cutout Dimensions Circular - 19.00mm Dia
Depth Behind Flange 41.50mm
Win Source Part Number 766832-KO119A7302
Popularity Medium
Supply and Demand Status Limited
Family Name KO
Introduction Date June 10, 2004
ECCN EAR99
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian KO119A7302 CAD Model

Description

{"FormattedDescription":"

The E-Switch KO119A7302 is a panel mount switch with 2 positions and a circuit of SPST.

  • Positions: 2
  • Circuit: SPST
  • Current Rating: 4A (AC)
  • Voltage Rating: 125V (AC)
  • Switch Function: Off-On
  • Actuator Type: Flat Key
  • Supply and Demand Status: Limited
  • Win Source Part Number: 766832
  • Series: KO
  • Panel Cutout Diameter: 19.00mm
  • Introduction Date: June 10, 2004
  • Estimated EOL Date: 2026
  • ECCN: EAR99
"}
