The FOD053LR2 is a 2-channel DC input high-speed logic gate output Optocoupler that combines a GaAsP light emitting diode and an integrated high gain photo detector. The output of the device is an open collector transistor and conforms to standard transistor-transistor logic (TTL) and complementary metal oxide semiconductor (CMOS) logic levels.

• Type: Optocoupler
• Channels: 2
• Input Type: DC
• Output Type: High-Speed Logic Gate
• Output: Open Collector Transistor
• Logic Levels: TTL and CMOS
• Package: 8-SO Tall
• Minimum DC Current Transfer Ratio: 15% @ 16mA
• Maximum DC Current Transfer Ratio: 50% @ 16mA
• Switching Turn-On Time: 1μs (Max)
• Switching Turn-Off Time: 1μs (Max)
• Maximum Output Voltage: 7V
• Forward Voltage: 1.45V
• Isolation Voltage: 2500Vrms
