AUIR3315S Real Image AUIR3315S real image15175
Same model may have multiple batches, images only for reference.
AUIR3315S Real Image AUIR3315S real image15175
AUIR3315S Real Image AUIR3315S real image15175
Same model may have multiple batches, images only for reference.

AUIR3315S

Part No AUIR3315S
Manufacturer Infineon Technologies
Catalog PMIC - Power Distribution Switches, Load Drivers
Description Current Limit SW 1-IN 1-OUT 6V to 32V 14A Automotive 5-Pin(4+Tab) D2PAK Tube / IC DVR CURR SENSE PROG D2PAK-5
Datasheet
AUIR3315S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type N-Channel
Voltage - Load 6 V to 32 V
Supply Voltage - Operating Not Required
Current - Output (Max) 14A
Rds On (Typ) 15 mOhm
Input Type Non-Inverting
Fault Protection Current Limiting (Adjustable), Over Temperature
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package D2PAK
Win Source Part Number 1020688-AUIR3315S
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AUIR3315
Introduction Date November 15, 2010
ECCN EAR99
Country of Origin Mexico
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian AUIR3315S CAD Model

Description

The 1020688-AUIR3315S is an N-channel MOSFET from Infineon Technologies designed for general-purpose switching applications.

  • Current Output: 14A
  • Voltage Load: 6V to 32V
  • Features: Adjustable current limiting and over-temperature protection
  • On-Resistance: 15mOhm
  • Package: D2PAK
  • Family: AUIR3315
  • Popularity: High
  • Supply and Demand Status: Balanced
