Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 52.3A (DC)
Voltage - Forward (Vf) (Max) @ If 2V @ 30A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 126ns
Current - Reverse Leakage @ Vr 50μA @ 600V
Mounting SMD (SMT)
Case / Package PG-TO263-3-2
Operating Temperature - Junction -40°C to 175°C
Win Source Part Number 068611-IDB30E60
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name IDB30E60
Introduction Date December 06, 2001
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian IDB30E60 CAD Model

Description

The IDB30E60 is a fast recovery diode electronic component manufactured by Infineon Technologies.

  • Case: PG-TO263-3-2
  • Maximum Voltage: 600V
  • Current: 52.3A (DC)
  • This component is commonly used in discrete semiconductor products such as portable electronics, automotive systems, and industrial automation equipment.
  • Reverse Recovery Time: 126ns
  • It is designed for use in fast recovery applications.
