ISL6269AEVAL2Z Intersil
Same model may have multiple batches, images only for reference.

ISL6269AEVAL2Z

Part No ISL6269AEVAL2Z
Manufacturer Intersil
Catalog Evaluation Boards - DC/DC & AC/DC (Off - Line)SMPS
Description EVALUATION BOARD FOR ISL6269A / ISL6269A Evaluation Board
Datasheet
ISL6269AEVAL2Z Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Intersil
Series Robust Ripple Regulator (R3)
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 1.1V or 1.2V
Output Current 5A
Voltage - Input 5 V ~ 25 V
Regulator Topology Buck
Frequency - Switching 300kHz or 600kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part ISL6269A, ISL6269B
Win Source Part Number 778167-ISL6269AEVAL2Z
Popularity Medium
Supply and Demand Status Limited
Family Name ISL6269A
Introduction Date January 19, 2004
ECCN EAR99
Country of Origin United States of America
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian ISL6269AEVAL2Z CAD Model

Description

The Intersil 778167-ISL6269AEVAL2Z is a development board that is designed for DC/DC step down applications.

  • ICs: ISL6269A, ISL6269B
  • Voltage Output: 1.1V or 1.2V
  • Board Status: Fully Populated
  • Output Type: Non-Isolated
  • Switching Frequency: 300kHz or 600kHz
  • Maximum Output Current: 5A
  • Popularity: Medium
  • Supply and Demand Status: Limited
  • Compliance: EAR99
  • Estimated EOL Date: 2028
