Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Linear Technology
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 1.8V, 2.5V or 3.3V
Output Current 1.25A
Voltage - Input 2.5 V ~ 5.5 V
Regulator Topology Buck
Frequency - Switching 1MHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part LTC3411A
Win Source Part Number 783330-DC1176A
Popularity Medium
Supply and Demand Status Limited
Introduction Date July 28, 2008
ECCN EAR99
Country of Origin United States of America
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian DC1176A CAD Model

Description

Introducing the DC1176A Demonstration Board from Linear Technology

The DC1176A is a state-of-the-art demonstration board from Linear Technology, now part of Analog Devices, designed for evaluating the performance of the LTC®3880. This board is a testament to the innovative engineering that Linear Technology is known for, offering a dual, polyphase synchronous step-down DC/DC controller with I<sup>2C-based PMBus interface for real-time monitoring and control of power systems.

The LTC3880 at the heart of the DC1176A is a feature-rich solution, providing precision voltage regulation with telemetry. This controller integrates key features such as voltage, current, and temperature monitoring, which can be accessed through the PMBus interface. The LTC3880's digital interface enables programmable voltage, margining, and power-on sequencing. Additionally, this interface makes it possible to query fault status and record peak values for later inspection, which is crucial for high-reliability applications.

With the DC1176A, users can take advantage of the LTC3880's dual, 6-phase operation, which significantly reduces the required output capacitance and inductance to achieve fast transient response. This is particularly beneficial in applications that demand high performance, such as data communication processors and high-end servers.

The demonstration board is designed to be user-friendly and easily accessible for engineers and designers. The DC1176A comes equipped with onboard jumpers and test points that provide flexibility and ease of use. The layout and component selection have been optimized to showcase the LTC3880's capabilities, ensuring that users can evaluate the full potential of this advanced controller in their own power system designs.

For those looking to integrate the DC1176A into their systems, Linear Technology provides comprehensive documentation, including detailed schematics, layout files, and configuration guides. This support ensures a smooth integration process and helps to reduce development time and effort.

In summary, the DC1176A demonstration board is an exemplary tool for exploring the capabilities of the LTC3880 and implementing advanced power management solutions. Whether for research, development, or production, the DC1176A is an invaluable asset for any power system designer seeking to enhance their designs with sophisticated power control and monitoring.
