Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Linear Technology
Main Purpose DC/DC, Step Down
Outputs and Type 1, Isolated
Voltage - Output 5V
Output Current 2.2A
Voltage - Input 10 V ~ 30 V
Regulator Topology Flyback
Frequency - Switching 345kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part LT8302
Win Source Part Number 766301-DC2014A
Popularity Medium
Supply and Demand Status Limited
Family Name DC2014A
Introduction Date October 23, 2013
ECCN EAR99
Country of Origin United States of America
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian DC2014A CAD Model

Description

Linear Technology's DC2014A Demonstration Board

The DC2014A is an advanced, high-performance demonstration board from Linear Technology, now part of Analog Devices, designed for evaluating the capabilities of the LTC3880 Dual Output PolyPhase Step-Down DC/DC Controller with I<sup>2C and PMBus Interface. This board is an excellent tool for engineers and developers to explore the features and benefits of the LTC3880 in a practical, real-world scenario.

Key Features:

  • Dual Output Configuration: The DC2014A is equipped with two channels, enabling it to manage dual outputs simultaneously, which is ideal for applications requiring multiple regulated voltages.
  • Efficient Power Management: With the LTC3880 at its core, the board provides precise control over power management, including output voltage, margining, and sequencing. This allows for optimized performance and power efficiency in complex systems.
  • Advanced Communication Interface: Integration of I<sup>2C and PMBus interface allows for intelligent system monitoring and control. This feature facilitates real-time adjustments and system diagnostics, enhancing the reliability and functionality of the overall design.
  • PolyPhase Capability: The LTC3880's PolyPhase operation supports scalability and phase interleaving, which reduces input and output ripple, improves thermal performance, and allows for smaller external components.
  • Robust Design: The DC2014A is built to handle a wide input voltage range and is capable of delivering high output current with excellent power conversion efficiency.

Applications:

The DC2014A is versatile and can be used in various applications, including:

  • Datacom and Telecom Systems
  • Industrial and Medical Equipment
  • Automotive Electronics
  • High-Density Distributed Power Systems

Technical Specifications:

  • Input Voltage Range: 4.5V to 24V
  • Output Voltage Range: 0.5V to 5.5V
  • Output Current: Up to 20A per channel
  • High Efficiency: Up to 95%
  • Operating Temperature Range: -40°C to 125°C

Overall, the DC2014A demonstration board is an exceptional tool for exploring the features of the LTC3880 controller and is an asset for any power system designer looking for a robust, efficient, and intelligent power management solution.
