Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology/Analog Devices
Packaging Tube
Amplifier Type General Purpose
Output Type Rail-to-Rail
Slew Rate 25V/μs
Gain Bandwidth Product 80MHz
Current - Input Bias 25nA
Voltage - Input Offset 75μV
Supply Current 1.6mA
Current - Output / Channel 50mA
Supply Voltage , Single/Dual (±) 2.3V ~ 12.6V, ±1.15V ~ 6.3V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SO
Family Part Number LT1801
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 1206310-LT1801IS8
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LT1801IS8 CAD Model

Description

The LT1801IS8 is a high-performance, low noise, dual operational amplifier from Linear Technology, now part of Analog Devices. This op amp is designed to offer a perfect balance of speed and power efficiency, making it suitable for a wide range of applications, including battery-powered devices, audio amplification, and signal conditioning in medical and industrial equipment.

Key Features:

  • Rail-to-Rail Input and Output: The LT1801IS8 can operate with input and output signals that extend to both supply rails, offering increased dynamic range in single or split supply operations.
  • Low Noise Performance: With its low voltage noise of just 8nV/√Hz at 1kHz, this op amp is ideal for applications that require minimal noise interference.
  • High Speed: A slew rate of 7.2V/μs and a gain bandwidth product of 80MHz make the LT1801IS8 suitable for fast signal processing applications.
  • Low Power Consumption: The device maintains its performance while consuming just 3.6mA of supply current per amplifier, which is beneficial for power-sensitive designs.
  • Wide Supply Range: It can operate from a supply range of 2.7V to 12.6V, accommodating various application requirements and simplifying power supply design.
  • Stable with Capacitive Loads: The LT1801IS8 is stable with capacitive loads up to 500pF, which is advantageous for driving capacitive loads without oscillation.

Package and Applications:

The LT1801IS8 comes in an 8-lead SO package, which is compact and suitable for space-constrained applications. Its versatility allows it to be used in a variety of circuits, ranging from simple audio amplifiers to complex filters and data acquisition systems. Whether you are designing a high-fidelity audio interface, a sensitive instrumentation circuit, or a battery-operated device, the LT1801IS8 delivers the performance you need.

Linear Technology's commitment to high-quality and reliable components is evident in the LT1801IS8's design and performance. Its combination of features makes it an excellent choice for designers looking for a dual op amp that does not compromise on speed, power efficiency, or noise performance.
