LT3085EMS8E#TRPBF Adjustable 500mA Single Resistor Low Dropout Regulator

The LT3085EMS8E#TRPBF is a versatile low dropout linear regulator (LDO) brought to you by Linear Technology, now part of Analog Devices. This high-performance component is designed to provide a stable and reliable power supply in a range of electronic applications. Its unique selling point is the ability to set the output voltage with just a single resistor, simplifying design and reducing external component count.

With an input voltage range from 1.8V to 20V, the LT3085 can deliver up to 500mA of continuous output current. This makes it suitable for a variety of applications, from powering sensitive analog circuits to acting as a post-regulator for switching power supplies. The device's low dropout voltage ensures efficient operation even when the input-to-output differential is small, enhancing battery life in portable applications.

The LT3085 features a wide output voltage range, adjustable from 0V to almost the full input voltage, giving designers the flexibility to use it in multiple configurations without the need for different regulator variants. The device's stability with ceramic, tantalum, or aluminum electrolytic capacitors offers additional design flexibility and can help in reducing the overall solution size.

Thermal performance is a key aspect of the LT3085, and it comes in an MSOP-8 package with a thermal resistance of 40°C/W. This, combined with internal protection circuits such as current limiting and thermal shutdown, ensures reliable operation under a variety of conditions. The LT3085 also features a

Finally, the LT3085EMS8E#TRPBF is RoHS compliant and lead-free, catering to environmentally conscious applications that require adherence to current international regulations. Whether you're designing power supplies for precision instruments, automotive electronics, or industrial control systems, the LT3085 offers a compact, efficient, and easy-to-use solution for your low dropout voltage regulation needs.
